Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability

Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability
Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability

Large Image :  Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability

Product Details:
Place of Origin: CHINA
Brand Name: TAITE
Certification: ISO9001:2015
Model Number: T300X55X80
Payment & Shipping Terms:
Minimum Order Quantity: 20
Packaging Details: Pallet or Nude
Delivery Time: 15 Days
Supply Ability: 3000 pcs/month

Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability

Description
Name: Rubber Excavator Tracks Size: T300X55X80
Length: 4400mm Material: Rubber, Steel Cord
Color:: Black Certificate: ISO9001:2015
High Light:

undercarriage rubber tracks

,

replacement rubber tracks for excavators



1. Product


Excavator rubber track T300X55X80  for Excavator AIRMANN,FIAT-HITACHI, HITACHI etc..



2. Technological Parameters:


Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability 0

Track Size

(WidthxPitch)

Inner Guide Width (A) Outer Guide Width (B) Inner Height (C) Outer Height(D) Track Thickness(E) Lug Pattern Gude Type Max Machine Weight (kg) Remarks
180x72 23 64 29 26.5 59 B A 1000
180x72K 23 65.5 29 27 65 B C 1200 AVT
190x72 23 66 28.5 26 67 B A 1300
200x72 23 66 29 26 64 B A 1300
200x72K 23 65.5 29 27 65 B C 1400 AVT
230x72 24 74 29 27 70 B/I A 1600
230x72K 23 71 29 28 70 B C 1800 AVT
230x48 25 68.5 21.5 24 68 A D 2100 AVT
230x48K 25 64 19 19.6 61 A K 2100 AVT
230x96 25 68 21.5 23 68 A D 2100
250x48.5Y 27 65 20 18.5 74 K K 2500 AVT
250x52.5 30 79 23.5 22 75 A D 2500 AVT
250x72 23 78 30 27 71 B A 2000
250x72K 23 71 29 28 70 B C 2100 AVT
300x52.5N 29 80 24 20 74 A D 3500 AVT
300x52.5W 39 92 23 21 76 A D 3500 AVT
300x53K 31 85 24 21.5 76 A K 4000 AVT
300x55 28 82 24 25.5 83 A D 4000 AVT
300x109 36 93 25 27 87 A D 4000
320x52.5N 29 80 24 19 74 A D 4000 AVT
350x52.5W 39 92 23 21 76 A D 4500 AVT
350x54.5K 40 93 23.5 21.5 85 A K 4500 AVT
400x72.5N 36.5 95 26 24.5 90 A E 5500 AVT
400x72.5W 49 106 24 22.5 89 A D/E 6000 AVT
400x72.5K 47 107 23.5 22 87 A K 6000 AVT
450x71 40 112 30 25 100 A D/E 8000 AVT
450x76 49 118 28.5 30 106 A D/E 8000 AVT
450x81N 42 110 29.5 28 100 A D/E 8000 AVT
450X81W 53.5 136 29 33 106 A D/E 8000 AVT
450x83.5K 41 110 23 26 105 A K 8000 AVT
450x92 61 152 31.5 34.5 129 A D/E 12000 AVT





3. Product Description



  • Both continuous and overlapping technique for excavator rubber tracks

  • Both Conventional type or interchangeable type

  • More than 20 tread patterns for your selection

  • Advantage: We have our patented “AVT”(anti-vibration) design by an independent acoustic engineer in 2007, and after tests run on 3-5 tons excavators using both soft and hard surface and the average result was an amazing 75% less vibration than ordinary tracks without “AVT” design.

  • Machine model: excavator undercarriage parts rubber track.

  • Working terrain: Construction site

  • Supply ability: 10000pieces/month

Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability 1





4. Application


  1. Perfect compatible with Excavator AIRMANN,FIAT-HITACHI, HITACHI etc.
  2.  Also suitable for machines of other brands with similar undercarriage system.
  3.  Good for rigid construction site.


5. Adapted Model




Manufacturer Machine type orig. Track     TAITE-Track Alternative Remark
AIRMANN AX 30 300 55 80 300x55x80
AIRMANN AX 30-2 300 52.5 82 300x55x80
AIRMANN AX 30UR-3 300 52.5 82 300x55x80
AIRMANN AX 32U 300 52.5 82 300x55x80
AIRMANN AX 33MU 300 52.5 82 300x55x80
AIRMANN AX 33U 300 52.5 82 300x55x80
AIRMANN AX 34U-4, 1-type 300 52.5 82 300x55x80
AIRMANN AX 35 300 52.5 82 300x55x80
AIRMANN AX 35-2 300 52.5 82 300x55x80
AIRMANN HM 30 SGZ 300 52,5 82 300x55x80
CHIKUSUI CC 91 300 55 80 300x55x80
FIAT-HITACHI FH 30.2, 1-type 300 52.5 82 300x55x80
FIAT-HITACHI FH 30.2, 2-type 300 55 80 300x55x80
FIAT-HITACHI FH 30.2 plus, 2-type 300 52.5 82 300x55x80
FIAT-HITACHI FH 30.3 Plus 300 55 80 300x55x80
FIAT-HITACHI FH 35.2, 1-type 300 52.5 82 300x55x80
FIAT-HITACHI FH 35.2, 2-type 300 55 80 300x55x80
FIAT-HITACHI FH 35.2 plus, 1-type 300 52.5 82 300x55x80
FIAT-HITACHI FH 35.2 plus, 2-type 300 55 80 300x55x80
FIAT-HITACHI FH 35.3 Plus 300 55 80 300x55x80
HITACHI EX 30, 2-type 300 55 80 300x55x80
HITACHI EX 30 U 300 55 80 300x55x80
HITACHI EX 30 UR, 2-type 300 55 80 300x55x80   Inner flange track roller
HITACHI EX 30 UR-2 300 55 80 300x55x80   Inner flange track roller
HITACHI EX 30 UR-2C 300 55 80 300x55x80   Inner flange track roller
HITACHI EX 30 UR-3 300 55 80 300x55x80   Inner flange track roller
HITACHI EX 32 U 300 52.5 82 300x55x80
HITACHI EX 32 UE 300 52.5 82 300x55x80
HITACHI EX 33 MU 300 52.5 82 300x55x80
HITACHI EX 33 U 300 52.5 82 300x55x80   Inner flange track roller
HITACHI EX 34U-4, 1-type 300 52.5 82 300x55x80
HITACHI EX 35 300 55 82 300x55x80   Inner flange track roller
HITACHI EX 35-2 300 55 80 300x55x80   Inner flange track roller
HITACHI FH 30.2 300 55 80 300x55x80
HITACHI FH 30.2 Plus 300 55 80 300x55x80
HITACHI FH 35.2 300 55 80 300x55x80
HITACHI FH 35.2 Plus 300 55 80 300x55x80
HITACHI SH 30-2 300 55 80 300x55x80
HITACHI ZX 30 300 55 80 300x55x80   Inner flange track roller
HITACHI ZX 35 300 55 80 300x55x80   Inner flange track roller
MESSERSI M 32 300 54 80 300x55x80



6. Advantages


  1. Less damage to the ground surface
  2. Patented Anti-Vibration tech, low noise
  3.  Patented Anti-Vibration tech, less vibration;
  4. Patented Anti-Vibration tech, machine protection;
  5. Low ground contack specific pressure
  6. High tractive force
  7. Light weight comparing with iron track.
  8.  Easy to replace

7. Packing & Delivery



  • Pallet or Wooden Case
  • Lead Time : 15-30 days

Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability 2

Low Noise Hitachi Rubber Tracks , Undercarriage Rubber Tracks High Durability 3



8. About Us



Since its establishment, Taite strives to build a modern enterprise with high efficiency. Our company has built a laboratory with comprehensive equipments, as well as several workshops with advanced manufacturing facilities. Taite is qualified with ISO9001-2015 quality management system. Besides, we have also imported IATF16949 to guide our process control. In the workshop, Taite runs complete 6S management and lean production to ensure stable and high level quality of our products. In this way, Taite realizes an effective system to prevent failure and flaw during manufacturing, and reduces the deviation in supply chain. Moreover, these effort we have done enable us the ability to produce customized products for our clients.



9. Warranty:


  • Guarantee 1000 hours or one year starting from the B/L date, whichever comes first.
